DC VOLTAGE
Best 1 Year Total Accuracy |
3050A
|
3041A
|
3010A
|
DC VOLTAGE
Best 1 Year Total Accuracy |
0 - ±1000V
± 50 ppm |
0 - ±1000V
± 25ppm |
DC CURRENT
Best 1 Year Total Accuracy |
0 - ±22A
± 100ppm |
0 - ±30A
± 50ppm |
0 - ±30A
± 50ppm |
AC VOLTAGE
Best 1 Year Total Accuracy |
20mV - 1000V, 10Hz to 100kHz |
20mV - 1000V, 10Hz to 500kHz
0.04% |
20mV - 1000V, 10Hz - 1MHz
0.015% |
AC CURRENT
Best 1 Year Total Accuracy |
20uA - 22A, 10Hz to 10kHz
0.07% |
20uA - 30A, 10Hz to 10kHz
0.06% |
20uA - 30A, 10Hz to 10kHz
0.04% |
RESISTANCE (PASSIVE)
Best 1 Year Total Accuracy |
0 Ohms - 100 MOhms
60ppm |
0 Ohms - 1 GOhms
40ppm |
0 Ohms - 1GOhms
18ppm |
CAPACITANCE (PASSIVE)
Best 1 Year Total Accuracy |
10nF - 1uF
0.25% |
1nF - 10uF
0.25% |
1nF - 10uF
0.25% |
FREQUENCY
Best 1 Year Total Accuracy |
1Hz - 10MHz
20ppm |
1Hz - 10MHz
20ppm / 1ppm option |
1Hz - 10MHz
20ppm / 1ppm option |
TEMPERATURE (THERMOCOUPLE)
Best 1 Year Accuracy |
J / K / T / R / S / B / U / N / E / L / U / C / 10uV°C
± 0.09°C |
J / K / T / R / S / B / U / N / E / L / U / C / 10uV°C
± 0.09°C |
J / K / T / R / S / B / U / N / E / L / U / C / 10uV°C
± 0.09°C |
|
